| Manufacturer | GigaIPC |
| Product ID | QBiX-Lite-AMDA1605H-A1 |
| CPU | AMD Ryzen V1605B Embedded Processor 2.0 - 3.6 GHz 4 Cores / 8 Threads 25W TDP, 4MB L3 Cache, 2MB L2 Cache |
| Chipset | SoC |
| Memory | 2 x DDR4-2133MHz SODIMM slots Maximum 32GB capacity Dual Channel Notes: 32GB requires 2 x 16GB |
| Video | AMD Radeon Vega 8 Graphics 1100 MHz Supports up to 4 Displays Max Resolution: 4096x2160@60Hz Support EDID emulation with AMD Graphic Driver |
| Audio | Realtek ALC269 HD Audio |
| Storage Technology | SATA3 6Gb/s M.2: PCI-E x4 and SATA support |
| Connectivity | 2 x Realtek RTL8111HS GbE LAN |
| Expansion Slots | 1 x M.2 Slot (2230, WIFI/BT) 1 x Mini PCI-E slot (PCI-E x1, USB 2.0) with SIM Slot |
| Front Panel I/O | 2 x USB 3.0 2 x RJ45 GbE LAN 4 x HDMI 2 x USB 2.0 1 x Power Button w/ LED 1 x HDD Status LED 1 x 12-24V DC-IN |
| Rear Panel I/O | 1 x COM (RS232/422/485 and RI/5V/12V) 2 x USB 3.0 1 x Audio Out |
| Drive Support | 1 x 2.5" SATA Drive Bay 1 x M.2 slot (2280, PCI-E x4/SATA) |
| Power Supply | Wide Input 12-24V DC-IN 65W 19V AC-DC Adapter |
| Case Dimensions | 234 x 155 x 30mm 9.2" x 6.1" x 1.2" (in inches, approximate) |
| Mounting | Wallmount Brackets Optional VESA 75/100 |
| Environmental | Operating Temperature: 0°C to 50°C (32°F to 122°F) Non-Operating Temperature: -20°C to 70°C (-4°F to 158°F) Operating Humidty: 0% - 90% (non-condensing) Non-Operating Humidity: 0% - 95% (non-condensing) |
| Warranty | 3-Year Manufacturer's Limited Warranty |
PRODUCT ID: QBiX-Lite-AMDA1605H-A1
