| Manufacturer | ASUS |
| Product ID | RS700A-E13-RS12U-2KW10G |
| Model Number | RS700A-E13-RS12U |
| CPU | Supports 2 x AMD EPYC 9005 Series processors Socket SP5 Up to 400W TDP |
| Chipset | SoC |
| Memory | 24 x DDR5 DIMM slots (12 per CPU) DDR5 6400/5600 RDIMM/3DS RDIMM Maximum 3072GB Capacity |
| Video | Aspeed AST2600 |
| Storage Technology | 2 x M.2 22110/2280/2260 slots (PCI-E 3.0 x4) 1 x microSD slot 6 x MCIO x8 Connectors 12 x SATA 6Gb/s Ports Backplane: 6 x MCIO x8, 3 x SlimSAS x4 |
| Connectivity | 1 x Management LAN Port (ASMB12-iKVM) |
| Expansion | 2 x PCI-E 5.0 x16 slots (Full Height, Half Length) 2 x OCP 3.0 slot (PCI-E 5.0 x16) |
| Rear I/O | DC-SCM Board: 1 x Power Button with LED 1 x RJ45 GbE Management LAN 2 x USB 3.2 (Gen1) 1 x Mini DisplayPort 1 x Location Button with LED 1 x USB 3.2 (Gen1) Type-C |
| Front Panel I/O | 1 x Power Button with LED 5 x Status LED (Message, LAN) 1 x Location Switch with LED 1 x Reset Switch |
| Drive Support | 2 x M.2 22110/2280/2260 slots (PCI-E 3.0 x4) 12 x 2.5" NVMe/SATA Hot Swap Bays |
| Power Supply | 1+1 Redundant 2000W 80 PLUS Platinum PSU 100-127V~/220-240V~, 12A/10A (x2), 50/60Hz |
| Cooling | 8 x 40x56mm Middle Case Fans |
| Case Dimensions | 1U Rackmount 449 x 43.85 x 800mm 17.68" x 1.73" x 31.5" (in inches) |
| Environmental | Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Non-Operating Humidity: 20% to 95% (non-condensing) |
| Compliance | BSMI, CE, CB, RCM, FCC (Class A), ISED |
| Warranty | 3 Year Manufacturer's Limited Warranty |
PRODUCT ID: RS700A-E13-RS12U-2KW10G
